Features

Static pressure in duct or room applications

Ideal for clean rooms, hospitals, fume hoods, computer rooms, and other very low differential pressure applications

Monitors positive and negative pressure for application versatility

Flexibility: standard and fast response modes

Variable air volume system control

Filter status monitoring

Excellent tolerance to overpressure and vibration reduces field failures

High accuracy digital sensor maintains calibration and reduces callbacks

High reliability sensor technology for long-term maintenance-free operation

Switch-selectable ranges and scales reduce setup time and number of models to stock

Microprocessor-based design allows for digitally profiled sensor increasing product accuracy and reliability

Brass barb fittings prevent breakage and accomodate popular tubing sizes

Technical Details

Response Time Standard:

T95 in 20 sec, Fast: T95 in 2 sec, switch selectable

Proof Pressure

3 psid (20.6kPa)

Burst Pressure

5 psid (34.5kPa)

Temperature Effect

1" 0.05%/°C; 10"

Zero Drift (1-year)

1" 2.0% max.

Operating Environment

0°- 60°C (32° to 140°F); 0 to 90% RH non-condensing

Fittings Brass barb

0.24” (6.1mm) o.d.
