Features

Built-in Actuator, Real Time Clock, Sylk Bus

Uses the Echelon LonWorks Network Protocol

Built-in Zone Control Functions Include a Remote Wall Module Interface and a Scheduler

Microbridge Air Flow Sensor with Dual Integral Restrictor Design (PVL0000AS, PVL4022AS, PVL4024NS, PVL6436AS, and PVL6438NS Only)

Easy User Access to Air Flow Sensor Inputs

Actuator (PVL0000AS, PVL4022AS, and PVL6436AS Only) Mounts Directly Onto VAV Box Damper Shaft and has Up to 44 lb-in (5 Nm) Torque, 90-Degree Stroke, and 90 Second Timing at 60 Hz

All Wiring Connections are Made to Removable Terminal Blocks to Simplify Controller Installation and Replacement

Both Controller Housing and Actuator are UL Plenum Rated

Free Topology Transceiver (FTT) High-Speed 78 Kilobit Communications Network

Capable of Stand-Alone Operation, But Can Also Use LonWorks Bus Network Communications

Sylk Bus for Use with Sylk-Enabled Sensors

117 Controllers Per Q7751A,B Router when Configured as a Repeater

Field Configurable and Programmable for Control, Input, and Output Functions Using the NIAGARA FRAMEWORK Software

User-Defined Network Variables

Function Block Engine, Which Allows the Application Designer to Program the Controller to Perform a Wide Variety of HVAC Applications

Significant Event Notification, Periodic Update Capability, and Failure Detect (FD) When Network Inputs Fail to be Detected Within Their Configurable Time Frame

Technical Details

Power

24 VAC With a Valid Range of 20 to 30 VAC

Operating Temperature

32 F to 122 F

Approval

UL/cUL (E87741) Listed Under UL916 (Standard for Open Energy Management Equipment) With Plenum Rating Meets FCC Part 15, Subpart B, Class B (Radiated Emissions) Requirements

Programming Software

Niagara Tools

Type

Programmable, Stand-alone

Communication Network

Lonworks

Ports

FTT-10A LON

Power Voltage

VAC

Power Voltage Display

20 To 30 VAC
